Designed for its versatility and high capacity, the Trench•Era™ FP series drain system can accommodate a variety of high-flow trench drain applications. This robust fast drainage system was designed with the installer in mind. It comes with a standard 14-inch wide steel frame, which supports 1.5″ thick grates, 12″ wide (internal width) channels that are available in 8′ sections, and end pieces that serve as either closed or open pipe outlets/inlets. Prefabricated bottom outlets, corners, and tee sections are also available to assist in customizing to the needs of your project via a free quote.
Each kit includes:
- Frame (Galvanized)
- Channel
- Grates
- Hardware Pack
- Frame End Plate
- End Caps(Outlet/Inlet)
- Sealer
Grating
- FG1247R – (14″ Wide)
- Stainless Steel Slotted Grate – (Load Class C – DIN Rating)
- Actual dimensions : 14.59″ x 23.88″ x 1.5″
