PRODUCT DOCUMENTATION
-
DESCRIPTION
This pre-sloped polymer concrete trench drain kits uses the ULMA Type U100KX channel with integral stainless steel edging. It has an external width of 130 mm, an internal width of 100 mm, and is available in overall heights ranging between 130 mm and 280 mm. Channels are 1 meter in length and have a 0.5% slope. Locking system consists of locking bar CS100 and hex head screws. Installation hardware is included.
Each Kit Includes :
- Channel(s)
- Grate(s) - Locust BoOF (Baked on Oil Finish)
- Installation chair(s)
- Locking device(s)
- End Cap (not included with half channel)
- End Outlet (not included with half channel)
Half Meter/2-foot kits are intended to be an extension to kits and only include one install chair and no end caps/outlets. Other accessories are to be purchased separately if it is intended to be a stand-alone kit.
Ulma's U100KX channel fits Iron Age Designs decorative cast iron trench grating measuring 122 mm x 498 mm. This kit has the Locust pattern, which is available in either the raw casting or Baked on Oil Finish (BooF).
Please note all cast-iron grates begin to naturally rust with exposure to any form of moisture and will appear bright orange before settling to brown. With the baked-on oil finish, the grates will still rust, but not to the same extreme as a raw grate.
