POLYCAST DG0675G Class A Transverse Slotted HDPE 6"x24" (Nominal) Grate - Gray

Grate Width: 5.25"

Grate Thickness: 0.75"

Grate Material / Color / Finish: Plastic/HDPE - Gray

Manufacturer: Hubbell - POLYCAST

System: POLYCAST 500 and POLYCAST 600

Grate Load Class: Class A

Grate Pattern: TRANSVERSE SLOTTED

Grate Pattern Style: SLOTTED

Channel Material: Polymer Concrete - Polyester and Polymer Concrete - Vinyl Ester

Channel Frame / Edging: Frame - None, Edging - None, Edging - Galvanized, and Edging - Stainless

Application: General Purpose Drainage - Interior, General Purpose Drainage - External, Residential, and Sports Complex - Recreational

POLYCAST® 6″x24″ ADA Compliant Transverse Slotted HDPE Grate
Large project? Request a Quote

DG067G5G- DuraGuard HDPE longitudinal (transverse) slotted grate for the stainless SS600 Series and the POLYCAST® 600 Series and 700 Series trench drain systems by Hubbell. Use in corrosive applications or where sanitary conditions are necessary. Provides excellent chemical resistance and durability. When used in high velocity transverse sheet flow applications, the transverse slots create turbulence to improve entry of flow into channel. Not recommended for use with POLYCAST® 500 system as it will partially block flow within the channel.

ADA Compliant.
Color: Grey

Actual Dimensions: 5-3/16" x 23-7/8"

DG0675 Grate Specification Sheet

Locking device not included, for POLYCAST 600 locking device, CLICK HERE
