POLYCAST 500 Series Kit w/ DG0646R Reinforced Perforated Galvanized Grate- HDPE Frame

POLYCAST 500 Series Kit w/ DG0646R Reinforced Perforated Galvanized Grate- HDPE Frame

  • New Image Coming Soon
1 1

Drainage Kits

PCK5-DG0646R-PF-04

Installation Chairs Included
$660.34 USD
$0.00 USD $660.34 USD
Sale Sold out
Kit Length
View full details

Additional Information

  • Grate Width: 5.25"
  • Grate Thickness: 0.75"
  • Product Type: Channel Kit, Kit
  • Grate Material / Color / Finish: Galvanized Steel
  • Manufacturer: Polycast
  • System: Polycast 500
  • Grate Load Class: D
  • Grate Pattern: Perforated
  • Grate Pattern Style: Perforated
  • Channel Material: Polymer Concrete - Polyester
  • Frame/Edging: HDPE
  • Application: General Purpose Drainage - Interior, General Purpose Drainage - Exterior, Residential, Sport Complex - Recreational

Description

Installation Chairs Included

POLYCAST 500 shallow trench drain is 1.75” in depth, 6.25" wide and comes in 48” lengths . A bottom outlet will need to be core drilled for pipe connection.  Installation chairs are included and provide a tight joint between channels while aligning and leveling the drainage run.

Typical Applications

500 End View

  • Decks and Patios
  • Grocery Stores
  • Multi Level Garages
  • Parking Lots
  • Hotels
  • Swimming Pools

Grating:

  • Galvanized Reinforced Grate DG0646R - (Class D Load Rating with Frame)
  • Pattern: Perforated
  • Open Surface Area: 17%
  • Heel Proof
  • ADA Compliant

Each Kit Includes:

  • 48" POLYCAST 500 channel (1 for each 4' of kit ordered)
  • 24" HDPE Frame (2 per channel)
  • 48" Galvanized Steel Grate (1 per channel)
  • Grate Hold-down devices (2 per grate)
  • Installation Chairs
  • End Caps (2 per system)
  • Installation instructions
