Each Kit Includes:
48″ POLYCAST channel(s)
48″ Galvanized Steel Reinforced Slotted Grates
24″ HDPE Frame 2/channel
Grate Hold-down devices 2/grate
Installation Chairs
End Cap
End Outlet
POLYCAST 500 shallow trench drain is 1.75” in depth, 6.25" wide and comes in 48” lengths . A bottom outlet that will need to be core drilled for pipe connection. Installation chairs are included and provide a tight joint between channels while aligning and leveling the drainage run.
Typical Applications
- Multi Level Garages
- Parking Lots
- Elevated Slabs
- Hotels
- Swimming Pools
- Decks and Patios
- Grocery Stores
Grating:
-
Galvanized Reinforced Grate - (Class D Load Rating with Frame)
- Pattern: Slotted
- Open Surface Area: 17%
- Heel Proof
- ADA Compliant
Each Kit Includes:
- 48" POLYCAST 500 channel (1 for each 4' of kit ordered)
- 48" Galvanized Steel Grate (1 per channel)
- 24" HDPE Frame (2 per channel)
- Grate Hold-down devices (2 per grate)
- Installation Chairs
- End Caps (2 per system)
- Installation instructions
