Each Kit Includes:
- 48″ POLYCAST 500 channel (1 for each 4′ of kit ordered)
- 48″ Galvanized Steel Grate (1 per channel)
- 24″ Ductile Iron Frame (2 per channel)
- Grate Hold-down devices (2 per grate)
- Installation Chairs
- End Caps (2 per system)
- Installation instructions
POLYCAST 500 shallow trench drain is 1.75” in depth, 6.25" wide, and comes in 48” lengths. A bottom outlet will need to be core drilled for pipe connection. Installation chairs are included and provide a tight joint between channels while aligning and leveling the drainage run.
Typical Applications
- Multi Level Garages
- Parking Lots
- Elevated Slabs
- Hotels
- Swimming Pools
- Decks and Patios
- Grocery Stores
Grating:
-
Galvanized Reinforced Grate - (Class E Load Rating with Frame)
- Pattern: Slotted
- Open Surface Area: 17%
- Heel Proof
- ADA Compliant
DG0640R Grate Specification Sheet
Each Kit Includes:
- 48" POLYCAST 500 channel (1 for each 4' of kit ordered)
- 48" Galvanized Steel Grate (1 per channel)
- 24" Ductile Iron Frame (2 per channel)
- Grate Hold-down devices (2 per grate)
- Installation Chairs
- End Caps (2 per system)
- Installation instructions
